UPPER ANTERIORS MOSTDI REPLACEMENT AND TEMPORIZATION WITH EXISTING ACRYLIC PARTIAL


A SIMPLE PRACTICAL APPROACH TO IMPLANT REPLACEMENT
 OF UPPER ANTERIORS SANS BONE GRAFTS
 IN SPITE OF A NARROW RIDGE



P2513 WERE USED. P STANDS FOR PROSTHODONTIC HEAD.
25 IS THE DIAMETER IN mm. 13 IS THE THREADED LENGTH OF
 THE IMPLANT IN mm. THE UNIVERSAL DESIGN OF THE
 PROSTHODONTIC HEAD ALLOWS IT TO BE USED IN ALMOST
ALL CASES. THE PRINCIPLE OF ACCURATE PLACEMENT AKA
PROSTHODONTIC DRIVEN PLACEMENT OF THE IMPLANTS
MUST BE ASSIDOUSLY FOLLOWED.
AN ALGINATE IMPRESSION IS TAKEN AND THE RESULTING
MODEL SENT TO THE LAB FOR THE FINAL PFM BRIDGE.


THE EXISTING ACRYLIC PARTIAL TEETH ARE REMOVED FROM
 THE PLATE AND TEMPORARY CROWN AND BRIDGE ACRYLIC IS
USED TO FASHION THE TEMPORARY BRIDGE IN THE MOUTH AND
 CEMENTED AWAITING THE PERMANENT.
VIOLA!!!







Friday, October 5, 2012

LOWER AND UPPER FULL DENTURE STABILIZATION PROCEDURE SECRETS REVEALED



80 YEAR OLD GENTLEMAN
VERY LOOSE LOWER DENTURES





MARKED WITH INDELIBLE PENCIL




REVERSED MARKS ON DENTURE




TREPHINING A THROUGH HOLE



USE A 4mm DIAMETER TREPHINE
YES, IT IS THE SAME ONE WE USE FOR CUTTING A PRECISE HOLE IN BONE




A 1.3mm DIAMETER PARALLEL DRILL
FULL DEPTH
IN THIS CASE TO A DEPTH OF 10-15 mm SINCE THE MOSTDI THREADED LENGTH IS 10mm




A 2.1 mm DIAMETER DRILL
JUST ABOUT 5 mm DEPTH IS ENOUGH TO GO THROUGH THE CORTICAL PLATE



A MOSTDI





INITIAL PURCHASE INTO THE CORTICAL PLATE




CONTINUE WITH A DRIVER AND RACHET WRENCH
STOP AS SOON AS THE DRIVER REACHES THE GUM
THE COLLAR OF THE IMPLANT SHOULD BE ABOVE GUM ABOUT 0.5mm to 1.0mm
THIS IS TO FACILITATE CAPTURE OF THE DAD aka ORING AND HOUSING
 WITHIN THE DETNTURE
THE MOSTDI IS NOW AT THE CORRECT DEPTH OF INSERTION TO RECEIVE THE DAD
AKA DENTURE ANCHORAGE DEVICE




VITAL TO PLACE THE FIRST ONE ACCURATELY
THE REST CAN THEN FOLLOW SUIT




AFTER THE PLACEMENT OF ALL FOUR MOSTDIS
FOUR CORRESPONDING THROUGH HOLES ARE TREPHINED INTO THE DENTURE





CHECKED TO MAKE SURE THAT THE DENTURE CAN SEAT IN PASSIVELY OVER THE MOSTIDIS AND MOSTDIDADS




WHITE COLD CURE ACRYLIC IS USED
TEMPORARY BRIDGE MATERIAL CAN BE USED
BEFORE PLACEMENT THE THROUGH HOLES ARE BLOCKED WITH CELLOPHANE TAPE ON THE TEETH SIDE AND COLD CURE IS PLACED ON THE UNDERSIDE ASPECT OF THE THROUGH HOLES



THE MOSTDIDADS ARE SNAPPED ON
OBSERVE HOW THEY SIT SNUGLY FLUSH ONTO THE GUMS
NO COLD CURE CAN THEN FLOW INTO THE DADS
SHIMS ARE NOT REQUIRED




THE DENTURE IS INSERTED ACCURATELY AND SEATED IN GENTLY
THE PATIENT IS ASKED TO CLOSE AND BITE EVER SO GENTLY IN FULL INTERDIGITATION WITH THE UPPER DENTURE





FIVE MINUTES LATER ONCE THE COLD CURE IS SET, THE DENTURE IS SNAPPED OFF THE MOSTDIS O-BALL HEADS







AFTER TRIMMING OFF THE EXCESS EASILY SINCE THEY ARE WHITE IN COLOUR, THE DENTURE IS READY FOR INSERTION










THE PATIENT TRIPS OFF TO A TRANSFORMED LIFE OF BEING ABLE TO CHEW AND ENJOY THE JOYS OF LIFE AGAIN !

HELLO..... WAIT....
PATIENT IS STILL UNHAPPY BECAUSE
THE UPPER FULL DENTURE IS ALSO LOOSE !!

SO..... WE DULY STABILIZED THE UPPERS TOO


FIRST WE MAKE THE NECESSARY THROUGH HOLES


PROPER PRECISE PLANNING IS REQUIRED


IT IS VITAL TO GET THE FIRST MOSTDI AT ONE OF THE CENTRAL INCISORS
IN EXACTLY WHERE IT SHOULD BE
IN POSITION AND ANGULATION
THE REST IS A BREEZE... JUST FOLLOW THE FIRST



NOTE THAT THE MOSTDI IS PLACED WITH ABOUT 0.5 TO 1.0 mm
OF THE COLLAR ABOVE GUM

THIS IS TO FACILITATE THE TRAPPING OF THE DADS
INTO THE DENTURE DURING COLD CURE


HERE YOU SEE THE MOEKENG IN ACTION
A DEDICATED INSTRUMENT USED
TO PLACE THE DADS PRECISELY
JUST IN CASE IT FLIES OFF OR DISAPPEARS


THE DADS ARE ALL IN PLACE
NOTE THAT SHIMS ARE UNNECESSARY
THE DADS ARE DESIGNED TO OBVIATE THE NEED FOR SHIMS


THE DENTURE MUST SEAT PASSIVELY AROUND THE MOSTDIDADS



TEMPORARY CROWN AND BRIDGE COLD CURE IS USED
IT IS WHITE IN COLOUR AND EXCESS CAN THEREFORE
BE IDENTIFIED EASILY AND REMOVED




THE O-RINGS ARE ORTHODONTIC 120 LIGATURE ELASTICS
THIS SOLVES THE PROBLEM OF COST AND AVAILABILITY
MOST DENTISTS WILL HAVE THEM IN THEIR DRAWER
THE O-RINGS CAN BE REMOVED WITH A CURVED PROBE AND INSERTED WITH A PLUGGER

THERE IS A DEDICATED INSTRUMENT CALLED THE KAIFOO
WHICH CAN BE USED TO REMOVE AND INSERT IN A JIFFY








NOW THIS GUY CAN CHOMP OF YOUR FINGER IF YOU ARE NOT CAREFUL !!!




HOWEVER AFTER SEVERAL MONTHS, THE UPPER DENTURE WAS NOT AS STABLE AS HOPED FOR.
THIS IS MAINLY BECAUSE THE UPPER JAW BONE IS SOFTER AND THE IMPLANTS ARE MORE PRONE TO LOOSEN AND GET INFECTED. THIS IS ESPECIALLY SO BECAUSE THE PATIENTS REMOVES THE DENTURE AND PLACES IT IN SEVERAL TIMES A DAY.
THE LOWER JAW BONE IS HARDER AND THEREFORE IMPLANTS ON THE LOWER JAW ALMOST NEVER FAIL.

SO THE PATIENT OPTED TO HAVE HIS UPPER DENTURE FIXED PERMANENTLY AND SO AVOID HAVING TO PULL AND PUSH ON THE IMPLANT EACH TIME HE REMOVES AND REPLACES IT.
THE RESULT IS AS FOLLOWS. HE HAD NO MORE PROBLEMS SINCE AND CLAIMS THAT HE CAN EAT ALMOST ANYTHING.






AND IF YOU CAN AFFORD IT, YOU CAN REPLACE YOUR FIXED ACRYLIC DENTURE WITH A FIXED PORCELAIN BRIDGE.
OBSERVE THE FOLLOWING PICS OF ANOTHER PATIENT.
BOTH TYPES OF MATERIAL SEEM TO WORK QUITE WELL.



THE FIRST MOSTDI WHIZZ PLACED MUST BE EXACTLY RIGHT.
IT IS THE PRIMARY GUIDE FOR ALL THE REST
 WHICH MUST BE MORE OR LESS PARALLEL WITH THIS FIRST ONE.


THE PATIENT'S EXISTING DENTURE IS MODIFIED TO ACT AS A TEMPORARY.



OBSERVE THAT THERE ARE TWO O-BALL HEADS IN THE LEFT AND RIGHT CANINE AREA.
TWO DAD AKA DENTURE ANCHORAGE DEVICES WILL BE COLD CURED INTO THE DENTURE SO THAT IT CAN BE SNAPPED ON AND OFF.
THIS IS THE TEMPORARY PROSTHESIS FOR THE PATIENT TO USE
UNTIL THE PERMANENT ROUNDHOUSE PORCELAIN BONDED TO METAL BRIDGE IS CONSTRUCTED AND CEMENTED ON.


SEE THE DENTURE SNAPPED INTO PLACE AS A TEMPORARY MEASURE.




ROUNDHOUSE PFM BRIDGE READY.
NOTE THE CLEANING GROOVES BETWEEN THE ABUTMENT HOLES.
THESE ARE TO FACILITATE FLOSSING OUT OF ALL EXCESS CEMENT AFTER CEMENTATION.


A LITTLE GUMMY BUT THE PATIENT INSISTED HE LIKES IT THAT WAY.


HE MAY BE RIGHT SINCE HIS UPPER LIP IS QUITE LONG.


NICE SMILE AND A LIFE TRANSFORMED.
